FMX TD400-4002-3PH - Group 02 IM Motor Parameters

4-12
Group 02 IM Motor Parameters
Param.
#
Parameter Name Setting Range Default Unit
Control Mode
Notes
V/F SLV PM/SLV
02-00 No-Load Current Motor 1 0.01–600.00 KVA A

X X
02-01 Rated Current Motor 1
V/F mode: 10%–200% of AC Drive
rated current.
SLV mode: 25%–200% of AC Drive
rated current.
KVA A
 
X
02-03
Rated Rotation Speed
Motor 1
0–60000 KVA rpm
 
X
02-04 Rated Voltage Motor 1
240V: 50.0–240.0 230.0
V
 
X *8
480V: 100.0–480.0 460.0
02-05 Rated Power Motor 1 0.01–600.00 KVA kW
 
X
02-06 Rated Frequency Motor 1 4.8–599.0 50.0/60.0 Hz
 
X *8
02-07 Motor 1 Pole Number 2–16(Even) 4 -
 
X
02-09
Excitation Current
Motor 1
15%–70% of motor rated current - % X

X (Note)
02-10
Core Saturation
Coefficient 1
1–100 KVA % X

X
02-11
Core Saturation
Coefficient 2 Motor 1
1–100 KVA % X

X
02-12
Core Saturation
Coefficient 3 Motor 1
80–300 KVA % X

X
02-13 Core loss Motor 1 0.0–15.0 KVA %

X X
02-15
Line-to-line Resistance
Motor 1
1–60000 KVA Ω

X X
02-17
Leakage Inductance
Motor 1
0.01–200.00 KVA mH
 
X
02-19 No-Load Voltage Motor 1
240V: 50–240 KVA
V X

X
480V: 100–480 KVA
02-20 No-Load Current Motor 2 0.01–600.00 KVA A

X X
02-21 Rated Current Motor 2 10%–200% of AC Drive rated current KVA A

X X
02-22
Rated Rotation Speed
Motor 2
0–60000 KVA Rpm

X X *8
02-23 Rated Voltage Motor 2
240V: 50.0–240.0 230.0
V

X X
480V: 100.0–480.0 460.0
02-24 Rated Power Motor 2 0.01–600.00 KVA kW

X X
02-25 Rated Frequency Motor 2 4.8–599.0 50.0/60.0 Hz

X X *8
02-26 Motor 2 Pole Number 2–16 (Even) 4 -

X X
02-32
Line-to-line Resistance
Motor 2
0.001–60.000 KVA Ω

X X
02-33
Proportion of Motor
Leakage Inductance
0.1–15.0 KVA % X

X
02-34 Motor Slip Frequency 0.10–20.00 KVA Hz X

X
02-09:
It is not recommended to adjust this parameter. Use caution when adjusting Excitation Current.
*8: Parameter value / default setting is dependent on drive size / model
