Group 03 External Digital Input and Output Parameters
Param.
#
Parameter Name Default Setting Range Unit
Control Mode
Notes
V/F SLV PM/SLV
03-00
Multifunction Input
Terminal S1
0
0: Forward/Stop Command
1: Reverse/Stop Command
2: Multi-Speed/Position Setting
Command 1
3: Multi-Speed/Position Setting
Command 2
4: Multi-Speed/Position Setting
Command 3
5: Multi-Speed/Position Setting
Command 4
6: Forward Jog Run Command
7: Reverse Jog Run Command
8: UP Frequency Increasing Command
9: DOWN Frequency Decreasing
Command
10: Acceleration/ Deceleration Time
Selection
11: Inhibit Acceleration/ Deceleration
Command
12: Main/ Alternative Run Switch
Function
13: Main/ Alternative Frequency Switch
Function
14: Emergency Stop (decelerate to zero
and stop)
15: External Baseblock Command
(coast to stop)
16: PID Control Disabled
17: Fault Reset
18: Auto Run Mode Enable
19: Speed Search
20: Energy Saving
21: Reset PID integral value to Zero
22: Counter Input
23: Counter reset
24: PLC Input
25: Pulse width modulation
measurement (S3 only)
26: Pulse frequency measure (S3 only)
27: Local/Remote selection
28: Remote mode selection
29: Jog Frequency Selection
33: DC Braking
34: Speed Search 2
40: Motor 1/Motor 2 selection
47: Fire mode
48: KEB Acceleration
65: Short-circuit braking
66: PID Control Disable 2
68: External Fault
69: External Overload
70: 2-wire Jog
–
See parameter
details
03-01
Multifunction Input
Terminal S2
1
03-02
Multifunction Input
Terminal S3
2
03-03
Multifunction Input
Terminal S4
3
03-04
Multifunction Input
Terminal S5
4
03-05
Multifunction Input
Terminal S6
17
03-0X=25 and 03-0X=26:
Terminal S3 only.
