FMX TD400-4002-3PH - Group 22 PM Motor Parameters

4-39
Group 22 PM Motor Parameters
Param.
#
Parameters Setting Range Default Unit
Control Mode
Notes
V/F SLV PMSLV
22-00 PM Motor Rated Power 0.00–600.00 KVA kW X X

(note)
22-02 PM Motor Rated Current 25%–200% AC Drive rated current KVA A X X

(note)
22-03 PM Motor‘s Pole Number 2–96 KVA poles X X

(note)
22-04
PM Motor’s Rotation
Speed
6–65535 KVA rpm X X

(note)
22-05
PM Motor’s Maximum
Rotation Speed
6–65535 KVA rpm X X

(note)
22-06
PM Motor Rated
Frequency
4.8–599.0 KVA Hz X X

(note)
22-10 PM SLV Start Current 20% – 120% Motor Rated Current 50 % X X

22-11
I/F Mode Start Frequency
Switching Point
1.0 – 20.0 10 % X X

22-14
PM Motor Armature
Resistance
0.001 – 30.000 1 Ω X X

22-15
PM Motor D-axis
Inductance
0.01 –300.00 10 mH X X

22-16
PM Motor Q-axis
Inductance
0.01 – 300.00 10 mH X X

22-18 Flux-Weakening Limit 0–100 0 % X X

22-21 PM Motor Tuning
0: PM Motor Tuning is not Active.
1: Parameter Auto-tune
0 - X X

22-22 PM Motor Tuning Fault
0: No Faults
5: Loop Adjustment Timed Out
7: Other Motor Tuning Errors
9: Current Abnormal during Loop
Adjustment
0 - X X

*4
22-23 PMSLV acceleration time 0.1–10.0 1 Sec X X

22-25
Initial Position Detection
of PM Motor
0: Disable
1: Detected when AC Drive is running
1 - X X

20-00 to 20-06: Value will depend on motor data
*4: Read-only Parameter
Group 21 Torque And Position Control Parameters
Param.
#
Parameters Setting Range Default Unit
Control mode
Notes
V/F SLV PMSLV
21-05 Positive Torque Limit 0–300 150 % X
 
21-06 Negative Torque Limit 0–300 150 % X
 
21-07
Forward Regenerative
Torque Limit
0–300 150 % X
 
21-08
Reversal Regenerative
Torque Limit
0–300 150 % X
 
