Table 3-1: Parts Lists
No.
Items
Appearance
Usage
Remarks
1
Battery
Provide power
2
Positive output
cable
Connect the battery and
inverter
3
Negative output
cable
Connect the battery and
inverter
4
RS485
communication
line
Apply to Modbus
protocol. Connect the
battery and the
computer.
Used to
monitor and
debug the
battery
(Optional)
5
RS485
communication line
Battery cascade line.
Connect the RS485
communication interface
between the adjacent
battery
Standard
RJ45
network
cable
6
External switch line
Battery external switch
7
Cabinet bolt
Fix the battery on the
rack or cabinet
