FOAMICO MO 0145-4 - Table of Contents

2 MO 0145-4 NEXT 701613-18_UK 15-04-2019
Content
1. Introduction 4
1.1 Condition of liability 4
1.2 Guarantee conditions. 4
1.3 Protection against frost 4
1.4 Safekeeping 5
1.5 Declaration of conformity 5
2 Safety 5
2.1 Safety during operation of the system 5
2.2 Precautionary measures 5
2.3 Appropriate utilization 6
3 Models and symbols 7
3.1 Symbols 7
3.2 Models. 7
3.3 Model Overview 8
4 Installation 9
4.1 Safety instructions for Mounting and Installation 9
4.2 Location and Mounting 9
4.3 Water supply 9
4.4 Electrical Supply 9
4.5 Supply of Detergent and sanitizer 10
5 Operation 11
5.1 Start and stop procedure. 11
5.2 Rinsing operation 11
5.3 Foam operation 11
5.4 Spray disinfection. 11
5.5 Stop of operation 12
6 Troubleshooting / Failures 15
6.1 Troubleshooting 15
6.2 Failures control system 15
6.2.1 The pump does not start 15
6.2.2 The pump will not stop 16
6.2.3 Red light illuminated at the pump 16
6.2.4 Other faults. 17
7 Maintenance 18
7.1 Rinsing hose. 18
7.2 Nozzles. 18
7.3 Low pressure valves / guns 18
7.4 Couplings. 18
7.5 Ball valves. 18
7.6 Non-return valves 18
7.7 Suction filter / chemical hose. 18
8 Technical data 19
9 Spare parts 20
9.1 Enclosure Mobile unit MO 0145- 4. With and without compressor 20
9.2 Overview Mobile unit MO 0145-4 with compressor 21
9.3 Overview Mobile unit MO 0-5 without compressor 23
9.4 Pipe system Rinse and foam block 25
9.5 Spare parts Rinse and foam block. 1001040-44 - 1001218 26
9.6 Spare parts Rinse and foam block. 1001309-13 28
9.7 Spare parts foam and rinse block, positioning ring, injector 30
