FOCUS 4010/HT Dental Porcelain Furnace Page 6 Manual version 4.2.2013
1.2 Installation
1.3 Vacuum Pump Connection
1) Using the rubber vacuum tube and the band supplied:
1. Connect the nozzle of the vacuum pump to the rubber vacuum tube.
2. Connect the nozzle of the furnace to the other end of the rubber tube.
3. Check the band is well secured.
2) Plug the electrical power cord of the vacuum pump, into the electrical power
outlet of the vacuum pump, located on the rear panel of the furnace.
3) Check the position of the pump so that the vacuum tube will have an undisturbed
air flow.
1.4 Furnace Connection to Power Outlet
Check and ensure that the main power switch at the rear of the
furnace is turned off.
Connect the electrical power cord into the furnace power inlet. Plug
the electrical power cord into the wall power outlet.
Switch the MAIN POWER switch ON (located on the rear panel). You
will hear a single beep. The furnace is now in Stand-by mode. The
word “ON” in the program field.
Press the ON/OFF key on the front panel. The furnace is now in
Idle mode.
Press the [STOP/LIFT] key - the platform will descend
automatically.
Place the ceramic table on the platform!!!
The furnace is now ready for the Initial Operation Procedure.
