Focusrite 18i8 - Page 20

20
Please refer to the Focusrite Control User Guide for further details.
CH NO. INPUTS OUTPUTS
1 Input 1 Output 1
2 Input 2 Output 2
3 Input 3 Output 3
4 Input 4 Output 4
5 Input 5 Output 5
6 Input 6 Output 6
7 Input 7 S/PDIF 1
8 Input 8 S/PDIF 2
9 S/PDIF 1
10 S/PDIF 1
11 ADAT 1
12 ADAT 2
13 ADAT 3
14 ADAT 4
15
16
17
18
CH NO. INPUTS OUTPUTS
1 Input 1 Output 1
2 Input 2 Output 2
3 Input 3 Output 3
4 Input 4 Output 4
5 Input 5 Output 5
6 Input 6 Output 6
7 Input 7 S/PDIF 1
8 Input 8 S/PDIF 2
9 S/PDIF 1
10 S/PDIF 1
11
12
13
14
15
16
17
18
At 88.2 kHz and 96 kHz sample rates: At 176.4 kHz and 192 kHz sample rates:
