18
Physical and Electrical Characteristics
Analogue Inputs 1 to 4
Connectors
“Combo XLR” sockets: Mic/Line/Inst (Inputs 1 & 2); Mic/Line
(Inputs 3 & 4) on front panel
Mic/Line switching Automatic
Line/Instrument switching
(Inputs 1 & 2)
via Focusrite Control
Phantom power +48 V switches for inputs 1 & 2, 3 & 4
Analogue Inputs 5 to 8
Connectors 4 x balanced ¼” TRS jacks on rear panel
Analogue Outputs
Main outputs 4 x balanced ¼” TRS jacks on rear panel
Stereo headphone outputs 2 x ¼” TRS jack on front panel
Main monitor output level control
On front panel
Headphones level controls
Other I/O
ADAT Input
TOSLINK optical connector:
8 channels at 44.1/48 kHz
4 channels at 88.2/96 kHz
2 channels at 176.2/192 kHz
Optical S/PDIF input (selectable)
S/PDIF I/O 2 x phono (RCA)
Data connector (to Mac) 1 x Thunderbolt connector
MIDI I/O 2 x 5-pin DIN sockets
Weight and Dimensions
W x D x H 222 mm x 192 mm x 63.5 mm / 8.74” x 7.56” x 2.5”
Weight
1.35 kg
2.98 lbs
