85
Absence
• EQ shape = Peak
• Centre frequency = 3.9 kHz
• Q = 3.5
• Gain range = 0dB to –10 dB
Warmth
• EQ shape = Peak
• Centre frequency range = 120 Hz to 600 Hz
• Q in boost mode = 0.5
• Q in cut mode = 2
• Gain range = +8 to –12 dB
DE-ESSER
• Threshold hold range = -10 dBfs (+12 dBu) to
–40 dBfs (-18 dBu).
• De-esser ratio at centre frequency = 2:1
• Centre frequency range = 2.2 kHz to 10 kHz
• Q of cut = 3.5
• Attack time = 0.5 ms
• Release time = 100 ms
• Noise = -94 dBu measured with a 20 Hz/22 kHz
bandpass filter.
OUTPUT METER
• Calibrated for 0 dBfs = +22 dBu and indicates the
level after the output fader being sent to both the
internal AD converter and the VoiceMaster Pro
XLR output.
• O/L LED is lit when any section of the unit
(including the headphone output) reaches a level
greater than 0 dBfs (O/L: LED triggered at +22.4
dBu).
WEIGHT
• 5 kg
DIMENSIONS
• 482 mm (W) x 88 mm (H) x 180 mm (D)
