3. Operating Controls and Displays
3.1 Unit
1. Main switch
2. Patient positioning mirror
3. Bite block
4. Image receptor
5. Height adjustment buttons
6. Knob for Frankfurt plane adjustment
7. Control panel
8. Optional self standing base
