Force 10 Marine - Plumbing Connections

Page 4 of 10
ENG-0092.6
PLUMBING CONNECTIONS
2
5
3
4
1
6
2
6
5
4
7
1
8
3
1. Cold Water In
2. Drain Valve
3. Heat Exchanger Inlet
4. Heat Exchanger
Return
5. SRV
6. Hot Water Out
1. Cold Water In
2. Drain Valve
3. Heat Exchanger Inlet
4. Heat Exchanger
Return
5. SRV
6. Hot Water out
7. TCV
8. TCV Adjustment Nut
Model with TCV)
Standard model without (TCV)
