STEP 18
Attach the right front vertical frame(6#) onto the right stabilizer(1#), Secure them with 2pcs M12*85 Hex bolt
(84#),4pcs φ12 washer (74#) and 2 pcM12 Aircraft nut (75#).
Use the same way to install another one.
