Force F-X15-V2 - Page 35

49
38
25
112
111
3925
25
40
110
113
49
38
112 2549
25103
115
103
25
49
116
110
37
114
37
116
Sliding Sleeve Right
1
110
Bushing 75-89
2
111
Internal Thread Shaft
Φ19.8*50
1
112
Powder Sleeve
φ33×φ29×φ20×18
2
49
Hexagon Bolt M10×25
4
38
Spring Washer
φ10
2
25
Flat Washer
φ10
10
113
Three Pulley Weldment
1
37
Pulley (96mm)
φ92 2
114 Pulley φ60 1
39
Hexagon Bolt
M10×45
3
40 Lock Nut
M10
3
115 Handgrip Tube φ25×2×138
1
103 Two Layer Spring Nut
φ23-M10
2
85
Umbrella Pin
φ12×M20×40
1
Key No. Description Note
Quantity
EXPLODED DIAGRAM
17.Pulley Slider - Right, 1 pc
34
F-X15-V2
