PARTS IDENTIFICATION
Key No.
Description
Base Frame - Left
Quantity
Parts Schematic Diagram
1 1
Rear Upright
2 2
Base Frame - Right
6 1
Rear Base Frame
7 1
Rear Base Fixing Plate
8
4
Front Upright - Left (silver)
12
1
Front Upright - Right (silver)
13
1
Front External Base
Fixing Plate - Left
14
1
Front External Base
Fixing Plate - Right
15
1
Pulley Slider - Left
16
1
Pulley Slider - Right
17 1
5
