PARTS IDENTIFICATION
Key No.
Description
Quantity
Parts Schematic Diagram
Weight Stack Guide Rod
18 4
Weight Stack
(Includes Top Weight Plate)
19 2
Weight Stack Pulley Frame
20
2
Rubber Bumper - Weight Stack
21
4
Weight Stack Selector Pin
22
2
Weight Stack Locking Shaft
23
4
Internal Hex Column Screw
24
4
Upper Frame - Right
27
1
Upper Frame - Left
29 1
Logo Board
30 1
Rear External Top Fixing Plate
31 2
6
