PARTS IDENTIFICATION
Key No.
Description
Quantity
Parts Schematic Diagram
Front External Top
Fixing Plate - Left
32 1
Front Internal Top Fixing Plate
33
2
Front External Top
Fixing Plate - Right
34
1
Chin Up Frame
35
1
Pulley Cover
36
12
Pulley (96mm)
37
16
Weight Stack Cable
42 2
External Weight Stack Shield
43
2
Plate Storage Horn46
8
Spring Collars
47 8
Core Trainer Bracket
50
1
7
