5
6
9
7
7
8
8
7
7
9
5
Rear Lower Connection Frame
1
6
Rear Upper Connection Frame
1
7
Flat Washer
φ10 16
8 Lock Nut M10 8
9 Hexagon Bolt M10×75 8
ASSEMBLY STEP 2
Key No.
Description
Note
Quantity
14
F-G12-V2
