11
10
9
7
8
7
9
7 Flat Washer φ10 8
8 Lock Nut M10 4
9 Hexagon Bolt M10×75 4
10
Base Bending Frame - Left
1
11
Base Bending Frame - Right
1
ASSEMBLY STEP 3
Key No.
Description
Note
Quantity
15
F-G12-V2
