13 12
8
7
9
7
9
8
7 Flat Washer φ10 8
8 Lock Nut M10 4
9 Hexagon Bolt M10×75 4
12
Upper Bending Frame - Right
1
13
Upper Bending Frame - Left
1
ASSEMBLY STEP 4
Key No.
Description
Note
Quantity
16
F-G12-V2
