Force G12-V2 User Manual

Upright Tube, 2 pcs
Chin Up Bar, 1 pc
106
49
102
107
108
70
69
118
117
116119
49 Flat Washer
φ12
12
102 Oval Pad
131*80
1
106 Hexagon Bolt
M12×25
12
107 Upright Tube
φ25*M12*98
12
108 Inner Plug
□50×50×1.2
1
69 Flat Washer
φ8
2
70 Lock Nut
M8
2
116 Logo Plate
T1
1
117 Hanging Ring 1
118 Round Tube Plug
φ32×1.5
6
119 Oblate Core-pulling Rivet
4×10
4
EXPLODED DIAGRAM
Key No.
Description
Note
Quantity
Key No.
Description
Note
Quantity
37
F-G12-V2

Force G12-V2 Specifications
