Force G12-V2 - Page 39

Sliding Tube Left, 1 pc
Sliding Tube Right, 1 pc
115
33
112109
111
8
113
75
7
110
53
58
114
7 Flat Washer φ10 8
8 Lock Nut M10 2
33 Hexagon Bolt M10×25 4
53
Pulley (96mm)
φ92 2
58 Hexagon Bolt M10×45 2
75
Metal Bushing
φ33×φ29×φ20×18 2
109 Spring Pin M20×1.5-φ10 1
110 Internal Thread Shaft Φ20*67 1
111 Pulley Rotating Sleeve 1
112 Spring Gasket φ10 4
113 Bushing 50-60 2
114 Handgrip Tube φ25*2 1
115 Two Layer Spring Slice Nut φ23-M10 2
EXPLODED DIAGRAM
Key No.
Description Note Quantity
38
F-G12-V2
