Assembly Instructions
Step 7
Attach the Weight Stack Cover16# and 2pcs Weight stack Bracket(29#) as the diagram show,
Secure them with 8pcs M6×20mm Allen Bolt(#71),10 pcs φ6 washers(#75),2pcs M6 Allen Bolt(78#),
12
