Next Generation Firewall Hardware Guide | Models N120W, N120WL,and N120L
Indicator Color Description
Unlit No link.Activity/
link status
light for
each
Ethernet
port
(Activity)
Green Link OK. Flashes on activity.
Unlit
10 Mbps link.
Amber 100 Mbps link.
Link
speed
light for
each
Ethernet
port (Link)
Green 1 Gbps link.
Unlit
The initial configuration has not yet been generated.
Amber Flashes while initial contact is being established. Steady amber when initial contact
has been established, but the NGFW Engine is offline.
Alternates with green when the NGFW Engine is in the standby state.
Status
Green Flashes when initial contact is established, but a policy has not been installed. Steady
green when the NGFW Engine is online.
Unlit
The NGFW Engine has made initial contact but no policy is yet installed.
MGMT
Green Flashes when the NGFW Engine tries to make initial contact or when the NGFW
Engine is reconnecting to the Log Server. Steady green when initial contact with
the Management Server has been made, the management connection has been
established, and a policy has been installed.
Unlit
The NGFW Engine does not have a clustering configuration.
HA
Green The NGFW Engine has a clustering configuration.
Unlit
There is no power feed to any of the Ethernet ports that support power over Ethernet
(PoE).
PoE
Green Power feed is active on at least one of the Ethernet ports that support PoE.
Unlit
There is no LTE connection.
Amber The signal strength of the LTE connection is weak.
Amber
and Green
The signal strength of the LTE connection is medium
LTE
(N120WL
and
N120L
only)
Green The signal strength of the LTE connection is good.
Unlit
No WLAN access point is available for clients to connect to.
Note: This indicator is not available in N120L appliance.
WLAN
(N120W
and
N120WL
only)
Green A WLAN access point is available for clients to connect to.
Note: This indicator is not available in N120L appliance.
Unlit
No power source is connected to the appliance.
PWR
Green Power is supplied to the appliance.
13
