Maintenance
and care
236
Replacing tail/brake/backup
lights and turn signal bulbs
(Coupe)
1. Open the tailgate.
2. From inside the luggage
compartment remove the wing nut
of the rear light assembly cover.
3. Using a Phillips screw driver
remove the screw. The lamp is still
retained by a spring loaded clip.
Remove by gently pulling out the
light housing.
4. Turn the bulb socket
counterclockwise as far as possible
and pull it out.
5. Pull the bulb straight out of the
socket and push in the new bulb.
6. Install the bulb socket in lamp
assembly by turning clockwise.
