Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
43 20A* Engine fan relay coil, A/C relay coil, IAC,
Mass air flow sensor, Heated exhaust gas
oxygen sensor, Catalyst module sensor,
Vapor management valve solenoid
44 15A* Ignition coil, Capacitor
45A — Not used
45B — Not used
46A — Fuel pump relay, Fuel injectors relay
46B — Not used
47 — Engine fan relay
48 — Starter relay
49 — Not used
50 — Not used
51 — Not used
52 — Not used
53 — Not used
54 — PCM relay
55 — Blower relay
56A — A/C clutch solenoid relay
56B — Fog lamp relay
* Mini Fuses ** Maxi Fuses
2009 Ranger (ran)
Owners Guide, 2nd Printing
USA (fus)
Roadside Emergencies
189
