Replacing
tail
lamp/backup
lamp
bulbs
1.
Make
sure
the
headlamp
switch
is
in
the
off
position
and
the
open
the
tailgate
to
expose
the
lamp
assemblies.
2.
Remove
the
four
screws
and
the
lamp
assembly
from
vehicle.
3.
Rotate
bulb
socket
counterclockwise
turn
and
remove
from
lamp
assembly
.
4.
Carefully
pull
the
bulb
straight
out
of
the
socket.
Install
the
new
bulb(s)
in
reverse
order
.
2009
Ranger
(ran)
Owners
Guide,
2nd
Printing
USA
(fus)
Lights
52
51
53
