ENGINE
DATA
Engine
2.3L
I4
engine
4.0L
V6
engine
Cubic
inches
138
245
Required
fuel
87
octane
87
octane
Firing
order
1-3-4-2
1-4-2-5-3-6
Ignition
system
EDIS
EDIS
Spark
plug
gap
0.049–0.053
inch
(1.25–1.35
mm)
0.052–0.056
inch
(1.32–1.42
mm)
Compression
ratio
9.7:1
9.7:1
Engine
drivebelt
routing
•
2.3L
I4
Engine
with
A/C
•
2.3L
I4
Engine
without
A/C
2009
Ranger
(ran)
Owners
Guide,
2nd
Printing
USA
(fus)
Maintenance
and
Specifications
263
262
264
