Item
Capacity
Ford
part
name
or
equivalent
Ford
part
number
/
Ford
specification
Engine
coolant
(2.3L
engine
with
manual
transmission)
10.5
quarts
(10.0L)
Motorcraft
Premium
Gold
Engine
Coolant
with
bittering
agent
(yellow-colored)
1
VC-7-B
/
WSS-M97B51-A1
Engine
coolant
(2.3L
engine
with
automatic
transmission)
10.2
quarts
(9.7L)
Engine
coolant
(4.0L
engine
with
manual
transmission)
13.7
quarts
(13.0L)
Engine
coolant
(4.0L
engine
with
automatic
transmission)
13.2
quarts
(12.5L)
Cooling
system
stop
leak
pellets
—
Motorcraft
Cooling
System
Stop
Leak
Pellets
VC-6
/
WSS-M99B37-B6
Engine
oil
(2.3L
engine)
4.0
quarts
(3.8L)
Motorcraft
SAE
5W
-20
Premium
Synthetic
Blend
Motor
Oil
(US)
Motorcraft
SAE
5W
-20
Super
Premium
Motor
Oil
(Canada)
2
XO-5W20-QSP
(US)
CXO-5W20-LSP12
(Canada)
/
WSS-M2C930-A
and
API
Certification
Mark
Engine
oil
(4.0L
engine)
5.0
quarts
(4.7L)
Motorcraft
SAE
5W
-30
Premium
Synthetic
Blend
Motor
Oil
(US)
Motorcraft
SAE
5W
-30
Super
Premium
Motor
Oil
(Canada)
2
XO-5W30-QSP
(US)
CXO-5W30-LSP12
(Canada)
/
WSS-M2C929-A
and
API
Certification
Mark
2009
Ranger
(ran)
Owners
Guide,
2nd
Printing
USA
(fus)
Maintenance
and
Specifications
260
259
261
