Ford 2012 Explorer - Page 365

2.0L EcoBoost™ engine
1. Engine coolant reservoir
2. Brake fluid reservoir
3. Battery
4. Power distribution box
5. Air filter assembly
6. Engine oil filler cap
7. Engine oil dipstick
8. Windshield washer fluid reservoir
1 2 3 4
7 6 5
8
Maintenance and Specifications
365
2012 Explorer (exp)
Owners Guide, 2nd Printing
USA (fus)
