PS19W:
1. Disconnect the electrical
connector (1) from the lamp
assembly. Disconnect the bulb
socket (2) from the lamp assembly
by squeezing the two tabs at the top
and bottom of the socket.
2. Pull bulb straight out of socket
and install the new bulb.
3. Install the bulb socket (2) by
pushing it directly into the lamp
assembly until the top and bottom
tabs snap into place. Reconnect the
electrical connector
W21W/WY21W:
1. Remove the bulb socket from the
lamp assembly by turning it
counterclockwise.
2. Pull bulb straight out of socket.
3. Install the new bulb in reverse
order.
Carefully install the tail lamp assembly on the vehicle by securing the
lamp assembly with two bolts. Reinstall bolt covers.
Replacing tail/brake lamp bulbs
For bulb replacement, see your authorized dealer.
2
1
Lights
84
2012 Explorer (exp)
Owners Guide, 2nd Printing
USA (fus)
