Fuse or relay
number
Fuse amp
rating
Protected components
59 10A* Brake on/off switch
60 15A* Stop lamps
61 10A* Rear seat release
62 10A* Air conditioner clutch
63 15A* Trailer tow stop/turn lamps relay
64 20A* Rear wiper motor
65 15A* Fuel pump
66 — Powertrain control module relay
67 20A* Vehicle power #2
68 15A* Vehicle power #4
69 15A* Vehicle power #1 (3.5/3.7L
engines)
20A* Vehicle power #1 (2.0L engine)
70 10A* Air conditioner relay, Vehicle
power #3, All-wheel drive module
(3.5/3.7L engines), Active grille
shutter (2.0L engine)
71 — Not used
72 — Not used
73 — Not used
74 — Not used
75 — Air conditioner clutch diode
(3.5/3.7L engines)
76 — Not used
77 — Trailer tow park lamps relay
78 20A* Right high-intensity discharge
headlamps
79 5A* Adaptive cruise control
80 — Not used
81 — Not used
82 15A* Rear washer
264 Fuses
2014 Edge (edg)
Owners Guide gf, 2nd Printing, March 2014
USA (fus)
