Fuse or relay
number
Fuse amp
rating
Protected components
83 — Not used
84 20A* Trailer tow park lamps
85 — Not used
86 7.5A* Powertrain control module relay,
Powertrain control module
keep-alive (3.5/3.7L engines)
87 5A* Run/start relay
88 — Run/start relay
89 — Not used
5A* Headlamp leveling motors
(China only)
90 10A* Powertrain control module,
Transmission Control Module
(2.0L engine)
91 10A* Adaptive cruise control (3.5/3.7L
engines)
5A* Automatic transmission warm-up
(2.0L engine)
92 10A* Anti-lock brake system module
93 5A* Blower motor/rear defroster relay
94 30A** Passenger compartment fuse
panel run/start
95 — Not used
96 — Canister purge solenoid diode
(2.0L engine)
97 — Automatic transmission warm-up
diode (2.0L engine)
98 — Air conditioner clutch relay
* Mini Fuses ** Cartridge Fuses
Fuses 265
2014 Edge (edg)
Owners Guide gf, 2nd Printing, March 2014
USA (fus)
