Protected componentsFuse amp ratingFuse or relay number
Not used—24
Run/start anti-lock brake system
10A
2
25
Run/start powertrain control module
10A
2
26
Not used (spare)
10A
1
27
Not used—28
Not used—29
Not used—30
Not used—31
Electronic fan #1 relay—32
Air conditioner clutch relay—33
Not used—34
Not used—35
Not used—36
Not used—37
Electronic fan #2 relay—38
Electronic fan #3 relay—39
Fuel pump relay—40
Horn relay—41
Not used—42
Not used—43
Not used—44
Not used—45
Alternator
10A
2
46
Brake on/off switch
10A
2
47
Horn
20A
1
48
228
Fusion (CC7) , enUSA
Fuses
To Next Page
