Ford 2014 FUSION - Page 232

Protected componentsFuse amp ratingFuse or relay number
Mass air flow monitor
5A
1
49
Not used—50
Not used—51
Not used—52
Power seats
10A
1
53
Not used—54
Not used—55
1
Micro fuse
2
Dual micro fuse
3
M-type fuse
Power Distribution Box - Bottom
There are fuses located on the bottom of
the fuse box. To access the bottom of the
fuse box, do the following:
E145983
1. Release the two latches, located on
both sides of the fuse box.
229
Fusion (CC7) , enUSA
Fuses
