Protected componentsFuse amp ratingFuse or relay number
Motor electronic cooling pump.10A*F25
Electronic power assist steering module
15.
5A*F26
Mass air flow sensor.5A*F27
Powertrain control module.15A*F28
Electronic air conditioning compressor.10A*F29
Positive temperature coefficient heater.
Engine control module.10A*F30
Powertrain control module.
Charge port light ring (C-MAX Energi).5A*F31
Vehicle power 2.20A*F32
Vehicle power 4.15A*F33
Injectors.10A*F34
Vehicle power 3.10A*F35
Vehicle power 1.20A*F36
Not used.—R1
Horn.Micro relayR2
Hybrid powertrain control.Micro relayR3
Front wiper.Micro relayR4
Not used.—R5
Front and rear wiper high-low.Micro relayR6
Vacuum pump.Power relayR7
Ignition feed.Power relayR8
Not used.—R9
Vacuum pump sensor.Mini relayR10
Not used.—R11
Cooling fan.Power relayR12
206
C-MAX (CCG) Canada/United States of America, enUSA, Second Printing
Fuses
