Protected componentsFuse amp ratingFuse or relay number
Washer pump.20AF77
Ignition switch, Start button.5AF78
Radio.15AF79
Hazard light switch.
Not used (spare).20AF80
Power sun shade.5AF81
Remote receiver antenna.
Washer pump ground.20AF82
Central locking ground.20AF83
Drive door unlock ground.20AF84
Electronic 15 feed.7.5AF85
Restraints control module.10AF86
Passenger air bag deactivation indicator.
Not used (spare).15AF87
Not used (spare).25AF88
Not used.—F89
Luggage Compartment Fuse Panel
The fuse panel is located in the luggage
compartment behind the left side wheel
well. Remove the fuse panel cover to gain
access to the fuses.
