Protected componentsFuse amp ratingFuse or relay number

Heater blower.Mini relayR13

Engine control relay.Mini relayR14

*Mini fuses **Cartridge fuses

Passenger Compartment Fuse

Panel

The fuse panel is located on the right-hand

side below the glove box. You may need

to remove a trim panel to access it.

E129926

207

C-MAX (CCG) Canada/United States of America, enUSA, Second Printing
