CUP HOLDERS

WARNING

Do not place hot drinks in the cup

holders when your vehicle is moving.

GLASSES HOLDER

89

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Storage Compartments
