Note: As the seats slide rearwards, they also
move slightly inboard.
4. Pull the lever on the outer front edge of
the outboard seats and push the seats
rearwards.
To return the seats to the forward position,
pull the lever and slide the seats forwards.
To return the center seat to its original
position, pull the lever on the underside of
the seat. Fold the center seat forwards and
push it back down fully until it engages.
Install the luggage cover.
Second row seats - Grand C-MAX
Stowing the center seat
WARNING
Make sure the center seat back is in
the upright position when the vehicle
is moving.
1. Pull the lever on the back of the center
seat and push the seatback down until
it locks.
2. Pull the strap and lift the right-hand
seat cushion.
8
C-MAX (CB7) Vehicles Built From: 10-09-2012, Vehicles Built Up To: 31-12-2014, CG3558en enGBR, Edition date: 03/2014, Second Printing
