Note: Make sure you align the tab in the air
filter element with the fork in the air cleaner
assembly tray.
5. Install the air cleaner assembly lid and
tighten the four fasteners.
Duratec Engines
1. Detach the 2 clips that secure the air
filter cover to the housing.
2. Carefully remove the air filter cover
from the housing. Do not detach any
connections or tubes from the cover.
3. Remove the air cleaner from the
housing.
4. Wipe any dirt or debris from the air filter
housing and cover to make sure that
no dirt gets into the engine.
5. Load the air filter into the housing.
6. Replace the air filter cover and secure
the clips.
260
Escape/Kuga (TM2), enUSA, First Printing
Maintenance
