Press
control
to
move
the
seat
forward,
backward,
up
or
down.
Adjustable
lumbar
support
T
urn
the
lumbar
support
dial
clockwise
to
adjust
firmness.
f12
_adjust_lumbar
f12
_rear_bench
Seating
and
safety
restraints
57
55
57
