Engine compartment
No. Description See page
Screen washer fluid reservoir 205
Engine coolant reservoir 202 - 203
Engine oil filler cap
1
199
Brake/clutch fluid reservoir 200
Battery 179
Auxiliary fuse box 155
Air cleaner
No maintenance
necessary
Engine oil dipstick
1
197 - 198
Power steering fluid reservoir 204
1 For easy identification, filler caps and the engine oil dipstick are marked in colour.
1.6l 16V BZ
Maintenance
195
Automatic transmission oil level guage 208
10
