39
Climate controls
Setting the temperature
Blue button: lower temperature.
Red button: higher temperature.
The temperature can be set
between
16
o
C
and
28
o
C
in steps of
0.5
o
C
using the buttons. In position
LO (below
16
o
C
) the system will
switch to permanent cooling, inHI
(above
28
o
C
) to permanent
heating, and not regulate a stable
temperature.
The sensor which measures the
interior temperature is located in
the centre of the heater control panel. The
sunload sensor is located on top of
the instrument panel. The sensors
should not be covered by any objectes.
For the system to function properly,
the side and centre vents should be
fully open.
At low outside temperatures, when
the system is in AUTO mode, the
air stream will be directed to the
front screen and the side windows
as long as the engine is cold.
Rear console adjustable vents (if equipped)
The airflow can be turned on or off with the rotary
control in the centre of the vents. Vents should be
either fully open (top detent) or fully closed (bottom
detent position).
The direction of the airflow can be adjusted
horizontally and vertically within the swivelling
range of the air vanes and vents.
