INSTALLING FOLD PLATES
Half fold diverter
Fold stop Fold stop knobs
Upper Fold Plate Lower Fold Plate
Fold stop
Upper Fold Plate
Install the upper fold plate at an angle, as shown. Align the notches on each side of the fold plate with the pins
on each side of the machine body. Push gently on the fold plate to lock it into position.
Upper fold plate pinsUpper fold plate notches
3
Upper fold plate
Upper fold plate seated on pins
