22
Service / Repair
Replacing a heating element (continuation)
11- Carefully lift the heater tray. This might
be a two person job.
12- Feed the element wires through the
holes in the tray and catch the element.
13- Fit the new element. 14- Replace the two nuts and washers that
secure the element to the tray.
9- Remove the loose insulation sleeves. 10- Position your hand underneath to catch
the element as it is released.
