Formech FM660 - Heater Wiring Diagram

N
1 2 5
4
3
6
E
1 2 3 4 5 6
16 Blue
8
Brown
3 Blue
8 Brown
DFGL
1.63mm
Lengths
Conduit cable: Lengths 3100mm
Single Phase 2 x 4mm SIAFGL.
Three phase =N Star.3 x 2.5mm, Neutral 4mm SIAFGL
Conduit, Adaptaflex 20mmwith Swivels @ 700mm
Cable chain 32 Links +End Bracket
Zone feeds
1.5mm SIAFGL
Red
Earth @ 2.5mm
SIAFGL G/Y
Stud
N
1 2 3 4 5 6
L
3
2
1
Formech FM660
Heater Wiring
Single
phase
Three Phase + N. Star
Heater wiring diagram Formech FM660
25
