fortessa FTDEVM2 - 2.4 System Diagrams

2.4 System Diagrams
2.4.1 Basic component diagram
A, For FTDEV1-4 and FTDEV5-8 kit
Video door station
Assist door panel
RVV2x1.0
2
mm
RVV2x1.0
2
mm
3wires
Video indoor phone
CAT5E
CAT5
Isolation module
Isolation module
PSU 32
PSU 12
5
