fortessa FTDEVM7 - Page 4

Switch hook
Alarm indicator
Unlock button
Keypad
Emergency button
Screw
Speaker
Handset
Microphone
Coil cord
Alarm-activated button
Model FTDEAH
Power te rminals
Rj45 port to door station
RJ45 ports to indoor phones
Power in dicator
RJ45 ports to next module(optional)
Isolation module FTDEIM
Power output terminals
Power indicators
Power input terminals
Power supply (12V&32V) FTDEPSU12 & FTDEPSU32
