Fortinet FortiGate Rugged 60F Series User Manual

54
BYPASS
STATUS
HA
POWER
FortiGate Rugged 60F
CONSOLE 1 2
SFP1
SFP2
SFP2WAN1
BYPASS
WAN2
3 4CONSOLE 1 2
SFP1
SFP1
SFP2
SFP2WAN1
BYPASS
Shared
Shared
WAN2
3 4
BYPASS
STATUS
HA
POWER
FortiGate Rugged 60F
CONSOLE 1 2
SFP1
SFP2
SFP2WAN1
BYPASS
WAN2
3 4CONSOLE 1 2
SFP1
SFP1
SFP2
SFP2WAN1
BYPASS
Shared
Shared
WAN2
3 4
1x QuickStart Guide
2x Ferrite Cores
4x Extended Rubber Feet
FortiGate Rugged 60F
Box Includes- FGR-60F
1x CAT5e Ethernet Cable
1x Wall Mount Bracket
Front Panel - FGR-60F
3
4
1
2
2
3
4
1
Console (RJ-45) CLI management computer connection
Ethernet Ports 1 to 4 (RJ-45) 1 Gbps Ethernet connections
5
6 7
USB (USB A) USB 2.0 server port
2x DC Power Connectors
1x DIN Rail Bracket
BYPASS
POWER
STATUS
HA
Green: PHY mode
Green: Device is on
Green: Operating normally
Green: HA enabled (normal)
Red: Bypass mode
Off: Device is off
Amber: Device error
Amber: HA enabled (failover)
Off: HA disabled
Flashing Green: Device startup
FGR-60F
BYPASS
STATUS
HA
POWER
FortiGate Rugged 60F
USB
CONSOLE 1 2 SFP1
SFP1
SFP2
SFP2WAN1
BYPASS
WAN2
3 4
5
6
7
Shared WAN1 & WAN2 Ports (RJ-45) 1 Gbps Ethernet connections
Shared SFP1 & SFP2 Ports (SFP) 1 Gbps Ethernet connections
LAN/WAN Bypass (RJ-45) 1 Gbps Ethernet connections
Speed
Link/Act
Ethernet & WAN Link/Act
Green: Connected
Flashing Green: Data activity
Off: No link established
Ethernet & WAN Speed
Green: Connected at 1000Mbps
Amber: Connected at 100Mbps
Off: 10Mbpps or no link established
Green: Connected at 1000Mbps
Off: No link established
Flashing Green: 1000Mbps activity
SFP Speed
SFP LED Indicators
Ethernet LED Indicators
SFP Activity
NOTE: WAN1/WAN2 and SFP1/SFP2 are shared interfaces
Wall Mount & Bracket Scews
(1 set of Bracket Screws for the DIN or Wall Bracket)
