Rear Panel - FGR-60F
2 3 4 6
5
1
1
2
3
4
5
6
RESET button
Ground Screw (#12 AWG) optional ground connection
Earth Ground (Lug Plate) ground connection
SERIAL Port (DB9) RS232 connection
Power Supply Indicators (DC1 & DC2) By default, Alarm is enabled in the OS*
Power Terminals (2 Pin Male) Redundant failover, 12V to 125V DC, 2A Max, see pg12
FGR-60F
Green: Power supply is on
Red: Alarm is on*; power supply not providing power or not connected
Off: Power supply is off
Green: Power supply is on
Red: Alarm is on*; power supply not providing power or not connected
Off: Power supply is off
DC1
DC2
